    • SeriesOGS 600
    • ApplicationOptical guidance
    • Trace typesLight trace on dark background, Dark trace on light background, Retro-reflective trace
  • Optical data
    • Working range10 ... 70 mm
    • Light sourceLED, Red
    • LED light wavelength634 nm
    • Detection width for complete trace265 mm
  • Measurement data
    • Measurement value resolution1 mm, Working distance 35 mm
    • Linearity error0 ... 5 mm, Working distance 35 mm
    • Output value for edges170 ... 2,830
    • Maximum output value0 ... 3,000
  • Electrical data
    • Performance data
      • Supply voltage18 ... 30 V, DC, Incl. residual ripple
    • Outputs
      • Number of digital switching outputs1 Piece(s)
      • Switching output 1
        • Switching elementTransistor, PNP
    • Inputs/outputs selectable
      • Number of inputs/outputs selectable1 Piece(s)
  • Timing
    • Cycle time10 ms
  • Interface
    • TypeRS 422
  • Connection
    • Number of connections1 Piece(s)
    • Connection 1
      • Type of connectionConnector
      • Thread sizeM12
      • No. of pins8 -pin
  • Mechanical data
    • Dimension (W x H x L)34.5 mm x 47.5 mm x 360 mm
    • Lens cover materialPlastic
    • Net weight405 g
  • Environmental data
    • Ambient temperature, operation-15 ... 50 °C
    • Ambient temperature, storage-30 ... 60 °C
  • Certifications
    • Degree of protectionIP 65
    • Standards appliedEN 60947-5-2:2007+A1:2012
  • Classification
    • Customs tariff number85365019
