<ERS-825A/IMS>
Type ERS-825A/IMS
Static friction torque Nm 120
Rated voltage DC-V 24
Power consumption W(at75°C) 23
Weight kg 11
Unit:mm





Diameter direction
A 218
A1 66.2
C 215
D 89.03
Shaft direction
L 75.3
M 55
N 3.3
P 34
Q 41.3
Mounting
NJ P.C.D 104.8
Bolt M8×16
Shaft hole
d 28
b 7
t 31
