ERS-400A/FMS Brake Sinfonia Vietnam ANSdanang

<ERS-400A/FMS>
Type ERS-400A/FMS
Static friction torque Nm 20
Rated voltage DC-V 24
Power consumption W(at75°C) 8
Weight kg 2.0
Unit:mm





Diameter direction
A 102
A1 31.8
C 102
C1 32
D 142.85
I 108
Shaft direction
L 59.5
M 38
N 2.4
P 24.5
Q 35
Mounting
K 4.7
KJ M6
NJ P.C.D 127
Bolt M6×18
Shaft hole
d 18
b 5
t 20
Controller
FMPR70/24D
