anhnghisonhcmList code VIBCO VIBRATORS 13-07-2026
1. Model: BVS-250 VIBCO VIBRATORS
BVS series foot mount "Silent" Pneumatic Turbine Vibrator,
designed for applications requiring medium amounts of
vibration.
Threaded exhaust port allows for porting air to remote location
if necessary. Cast iron housing standard (Aluminum
available).
12,000 VPM, 7.5 CFM, @ 80 PSI, with 480 lbs. of force. 72
dB.
Continuous Duty rated.
NO LUBRICATION REQUIRED
A filter-regulator is recommended for optimum life &
performance. Exhaust mufflers are available for quieter
operation.
2. Model: SET-12 VIBCO VIBRATORS
Mounting Hardware for BV/BVSV/VS-250/320, 50-1/1/4(S),
55-1/4(S),150(S), MLT/MHI-320, & SFC-100/300
Consist of:
(2) 1/2-13X1.75HHG5 Hext Hd. Cap Screws - Gr. 5
(2) 1/2-13HN Hex Nuts
(2) 1/2LW Lockwashers
(2) 1/2SAE Flatwashers
3. Model: 3X5CH-24 VIBCO VIBRATORS
* Mounting Channel to be used in conjunction with Mounting
Plate for proper installation of Vibrator. 24" Length of Channel
required is based on Vibrator size and bin wall thickness .
Important Note: This item is special/custom order. As such, it
is nonreturnable and nonrefundable
4. Model: 3/8 VIBCO VIBRATORS
3/8" NPT sintered bronze Exhaust Muffler.
To be used with pneumatic vibrators with thread exhaust ports
to help reduce noise from exhausting air.
175 cfm @ 80 psi
5. Model: 86102 VIBCO VIBRATORS
1/4" Ball Valve. 1/4" NPT thread. Bronze cast housing,
stainless steel ball.
For manually operating any pneumatic vibrators.
6. Model: 46102 VIBCO VIBRATORS
1/4" NPT Filter-Regulator combination with gage & mounting
bracket.
Max. Pressure :150 psi
Max. Flow: 18 CFM@ 80 PSI
5 Micron Filter
Factory recommended for all pneumatic vibrators, will help
performance and increase life of your vibrator
7. Model: 1/4SV VIBCO VIBRATORS
Solenoid Valve, 2-way, Normally Closed, 1/4" NPT.
3-150 PSI max., Cv = 2.0
110-120 VAC, 50/60 Hz, 10 Watt, Class F, NEMA 4X
UL Listed, CSA Certified
Brass body, NBR Seals, Max. Temperature 185° F (85° C)
To be used with any pneumatic vibrator for automatic or
remote operation. Can be used in conjunction with circuit
timer.
8. Model: BVM-3 VIBCO VIBRATORS
Pre-drilled & tapped steel Mounting Plate. Recommended for
easy installation on B,BV,BVS-250 Vibrators.
9. Model: BVS-510 VIBCO VIBRATORS
BVS series "Silent" Pneumatic Turbine Vibrator. Threaded
exhaust port.
Cast iron housing standard (Aluminum available).
5600 VPM, 21 CFM, @ 80 PSI, with 900 lbs. of force,
continuous duty.
NO LUBRICATION REQUIRED
Factory recommends filter/regulator for optimum
performance.
Exhaust mufflers are available for quieter operation .
10. Model: SET-33 VIBCO VIBRATORS
Vibrator Mounting Hardware for:
- BV/BVS-380, BVS-510
- 50/55-1-1/2 & 2(L). LI-16-I
- CCF-2000, SVRFS-4000(AL)
Consist of:
(2) 5/8-11 x 2-3/4" Hex Head Cap Screws Gr. 5
(2) 5/8-11 Hex Nuts
(2) 5/8 SAE Washers
(2) 5/8 Lock washers
11. Model: 4X6.25CH-48 VIBCO VIBRATORS
* 48" length of 4" x 6.25 lb/ft Mounting Channel to be used in
conjunction with Mounting Plate for proper installation of
Vibrator. Length of Channel is based on Vibrator size and
bin wall thickness.
Important Note: This item is special/custom order. As such, it
is nonreturnable and nonrefundable.
12. Model: 3/4 VIBCO VIBRATORS
3/4" NPT sintered bronze Exhaust Muffler.
To be used with pneumatic vibrators with thread exhaust ports
to help reduce noise from exhausting air.
13. Model: BVM-6 VIBCO VIBRATORS
Predrilled steel mounting plate. Recommended for easy installation on BV,BVS-440/510 vibrators.
14. Model: 4X6.25CH-48 VIBCO VIBRATORS
* 48" length of 4" x 6.25 lb/ft Mounting Channel to be used in conjunction with Mounting Plate for proper installation of Vibrator. Length of Channel is based on Vibrator size and bin wall thickness.
15. Model: SET-33 VIBCO VIBRATORS
Vibrator Mounting Hardware for:
- BV/BVS-380, BVS-510
- 50/55-1-1/2 & 2(L). LI-16-I
- CCF-2000, SVRFS-4000(AL)
Consist of:
(2) 5/8-11 x 2-3/4" Hex Head Cap Screws Gr. 5
(2) 5/8-11 Hex Nuts
(2) 5/8 SAE Washers
(2) 5/8 Lock washers
16. Model: 86124 VIBCO VIBRATORS
1/2" Ball valve. 1/2" NPTF thread. Bronze cast housing, stainless steel ball.
For manually operating any Pneumatic Vbrator or Air Cannons.
17. Model: 46124 VIBCO VIBRATORS
1/2" NPT Filter-Regulator combination with gage & mounting bracket.
Max. Pressure: 150 PSI
Max. Flow: 70 CFM @ 80 PSI
5 Micron Filter
Factory recommended for all pneumatic vibrators, will help performance and increase life of your vibrator.
18. Model: 1/2SV VIBCO VIBRATORS
Solenoid Valve, 2-way, Normally Closed, 1/2" NPT.
0-150 PSI max., Cv = 4.0
110-120 VAC, 50/60 Hz, 11 Watt, Class F, NEMA 4X
Brass body, NBR Seals, Max. Temperature 180° F (82° C)
To be used with any pneumatic vibrator for automatic or remote operation. Can be used in conjunction with circuit timer.
