Description

  • 50 to 1000 mm strokes
  • Cursor magnetic drag
  • Independent linearity up to ± 0.05%
  • Repeatibility: = 0.08 mm
  • Hysteresis: = 0.25 mm
  • Tracking error (see table)
  • Infinite resolution
  • No variation of electrical output signal outside theoretical electrical stroke
  • Working temperature: -30...+100°C
  • Electrical connection: 3-pole polyurethane screened cable with high flexibility (1m lenght)
  • AISI 316 stem and nipple
  • Lifetime: > 25x106 meters or >100x106 operations whichever is the smallest (within C.E.U.)
  • Max. working pressure 250 bar, 400 bar peak
