Variants
Order Code
Measuring range
Interface
Resolution
Reference signal
Read distance
BML-S1C0-Q53L-M400-M0-KA02 BML003L   Digital A/B, HTL ≤ 100 µm   0.01...2 mm
BML-S1C0-Q53L-M400-M0-KA05 BML003U   Digital A/B, HTL ≤ 100 µm   0.01...2 mm
BML-S1C0-Q53L-M400-R0-KA05 BML0069   Digital A/B, HTL ≤ 100 µm   0.01...2 mm
BML-S1C0-Q53P-M400-R0-KA05 BML005E   Digital A/B, HTL ≤ 1000 µm   0.01...2 mm
BML-S1C0-Q53R-M400-R0-KA05 BML00A3   Digital A/B, HTL ≤ 2000 µm   0.01...2 mm
BML-S1F1-A62Z-M300-90-KA05 BML008R   Analog, sin/cos   without reference signal 0.01...0.35 mm
BML-S1F1-A62Z-M310-90-KA00,3-S284 BML06WW   Analog, sin/cos   Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-A62Z-M310-90-KA02 BML0019   Analog, sin/cos   Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-A62Z-M310-90-KA05 BML02J1   Analog, sin/cos   Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-A62Z-M310-90-KA10 BML002U   Analog, sin/cos   Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-Q61D-M300-F0-SA23-KA02-ZA15 BML05PZ   Digital A/B, RS422 ≤ 1 µm without reference signal 0.01...0.35 mm
BML-S1F1-Q61D-M310-E0-KA05 BML032H   Digital A/B, RS422 ≤ 1 µm Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-Q61D-M310-F0-KA00,3-S284 BML062E   Digital A/B, RS422 ≤ 1 µm Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-Q61D-M310-F0-KA05 BML001A   Digital A/B, RS422 ≤ 1 µm Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-Q61D-M310-G0-SA24-KF01 BML0680   Digital A/B, RS422 ≤ 1 µm Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-Q61E-M500-E0-SA9-KA00,3-ZA13 BML05FY   Digital A/B, RS422 ≤ 2 µm without reference signal 0.01...1.25 mm
BML-S1F1-Q61E-M500-E0-SA9-KA00,3-ZA16 BML05WA   Digital A/B, RS422 ≤ 2 µm without reference signal 0.01...1.25 mm
BML-S1F1-Q61F-M310-D0-KA05 BML008P   Digital A/B, RS422 ≤ 5 µm Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-Q61F-M310-D0-KA15 BML033U   Digital A/B, RS422 ≤ 5 µm Individually or fixed-periodic 0.01...0.35 mm
BML-S1F1-Q61G-M300-F0-KA02 BML001C   Digital A/B, RS422 ≤ 10 µm without reference signal 0.01...0.35 mm
BML-S1F2-A62Z-M310-90-KA05 BML0001   Analog, sin/cos   Individually or fixed-periodic 0.01...0.35 mm
BML-S1F2-A62Z-M310-90-SA21-KA00,09-ZA10 BML051J   Analog, sin/cos   Individually or fixed-periodic 0.01...0.35 mm
BML-S1F2-Q61D-M310-G0-KA05 BML0140   Digital A/B, RS422 ≤ 1 µm Individually or fixed-periodic 0.01...0.35 mm
BML-S1F2-Q61D-M310-K0-KA00,3-S284 BML0694   Digital A/B, RS422 ≤ 1 µm Individually or fixed-periodic 0.01...0.35 mm
BML-S2B0-Q53F-M410-D0-KA05 BML0211   Digital A/B, HTL ≤ 5 µm Individually or fixed-periodic 0.01...2 mm
