ICS-ADL300 Integrated solution for elevators VIET NAM

Integrated solutions for elevators from 1.1 kW to 75 kW

* Power supply:

• ICS-ADL300-2T: 3 x 200-230Vca, 50/60Hz
• ICS-ADL300-2M: 1 x 200 Vca, 1 x 230 Vca, 50/60Hz
• ICS-ADL300-4: 3 x 230-400-480Vca, 50/60Hz

* Motor Ratings:

• ICS-ADL300-2T: 5,5 ... 37kW
• ICS-ADL300-2M: 1,1 ... 5,5kW
• ICS-ADL300-4: 4 ... 75kW

* Certifications:

CE (Directives LVD 2014/35/EC, EMC 2014/30/EC, Lift 2014/33/EC), cULus (UL508C), Safe Torque Off (STO) EN61800-5-2-2007 SIL3.

Features

• Type of motor: asynchronous and permanent magnet synchronous motors
• Integrated LED keypad
• Integrated EMI filter in -F models
• Choke:
  • ICS-ADL300-2T: DC choke: no, AC choke: external (optional)
  • ICS-ADL300-2M: no
  • ICS-ADL300-4: DC choke: integrated (from size 4300). For smaller sizes, it is external (optional); AC choke: external (optional)
• Braking system:
  • ICS-ADL300-2T integrated up to 30 kW with external resistor
  • ICS-ADL300-2M: integrated
  • ICS-ADL300-4: Integrated up to 55 kW with external resistor
• TTL / HTL, SinCos, Endat encoders
• Standard protection rating IP20
