Model: HT46CI/4P-M12 Cảm biến quang Diffuse sensor Leuze

Model: HT46CI/4P-M12 Cảm biến quang Diffuse sensor Leuze

Features:

Series: 46C

Operating principle: Diffuse reflection principle with background suppression

Black-white error: < 10% up to 1200 mm

Operating range, white 90%: 0.005 ... 3 m

Operating range, gray 18%: 0.02 ... 2 m

Operating range, black 6%: 0.05 ... 1.5 m

Operating range limit: 0.005 ... 3 m

Adjustment range: 120 ... 3,000 mm

Light source: LED, Infrared

Protective circuit: Polarity reversal protection, Short circuit protected, Transient protection

Supply voltage UB: 10 ... 30 V, DC, Incl. residual ripple

Residual ripple: 0 ... 15 %, From UB

Open-circuit current: 0 ... 30 mA
