- Operating range, white 90%0.007 ... 0.35 m
- Operating range, gray 18%0.01 ... 0.33 m
- Operating range, black 6%0.012 ... 0.3 m
- Operating range limit, white 90%0.007 ... 0.4 m
- Operating range limit, gray 18%0.01 ... 0.37 m
- Operating range limit, black 6%0.012 ... 0.34 m
- Light sourceLaser, Red
- Laser class2, IEC/EN 60825-1:2007
-
Electrical data
- Protective circuitPolarity reversal protection, Short circuit protected
-
Performance data
- Supply voltage10 ... 30 V, DC
- Residual ripple0 ... 15 %, From UB
- Open-circuit current0 ... 35 mA
