Bộ khuếch đại DC (Amplifier DC)

Model: STC 425 K (Id-no: P10632)

Specifications

Type

STC 425 K

Surface roughness [µm]

≤0.8

Supply voltage [V]

-

Current consumption [mA]

-

Switching current [mA]

-

Ambient temperature [ ⁰C]

-20...+80

Medium temperature [ ⁰C]

+20...+120

Temperature gradient [K/m]

250

Start-up time [s]

8 (2…15)

Reaction time typ. [s]

2 (1…13)

Compressive strength [bar]

100

Housing material

AISI 316 L/ PVDF (cable gland)

Protection

IP68

Connection

2 m FEP-cable 4x0.25 mm2
