Variants
 |
Order Code
|
Housing material
|
Dimension
|
Switching output
|
Connection
|
Connection type
|
|---|---|---|---|---|---|---|---|
 |
BMF 07M-NS-C-2-KPU-02 | BMF0008 | Brass | Ø 6.5 x 30.5 mm | NPN Normally open (NO) | Cable, 2.00 m, PUR | |
|
BMF 07M-NS-C-2-KPU-03 | BMF0009 | Brass | Ø 6.5 x 30.5 mm | NPN Normally open (NO) | Cable, 3.00 m, PUR | |
 |
BMF 07M-NS-D-2-S49-00,3 | BMF000A | Brass | Ø 6.5 x 30 mm | NPN Normally open (NO) | M8x1-Male, 3-pole | Cable with connector, 0.30 m, PUR |
 |
BMF 07M-NS-D-2-SA2-S49-00,3 | BMF000C | Brass | Ø 6.5 x 30 mm | NPN Normally open (NO) | M8x1-Male, 3-pole | Cable with connector, 0.30 m, PUR |
|
BMF 07M-PS-C-2-KPU-02 | BMF000E | Brass | Ø 6.5 x 30.5 mm | PNP Normally open (NO) | Cable, 2.00 m, PUR | |
|
BMF 07M-PS-C-2-KPU-03 | BMF000F | Brass | Ø 6.5 x 30.5 mm | PNP Normally open (NO) | Cable, 3.00 m, PUR | |
 |
BMF 07M-PS-D-2-S4-00,6 | BMF000J | Brass | Ø 6.5 x 30 mm | PNP Normally open (NO) | M12x1-Male, 4-pole, A-coded | Cable with connector, 0.60 m, PUR |
|
BMF 07M-PS-D-2-S49-00,3 | BMF000K | Brass | Ø 6.5 x 30 mm | PNP Normally open (NO) | M8x1-Male, 3-pole | Cable with connector, 0.30 m, PUR |
|
BMF 07M-PS-D-2-SA2-S49-00,3 | BMF000L | Brass | Ø 6.5 x 30 mm | PNP Normally open (NO) | M8x1-Male, 3-pole | Cable with connector, 0.30 m, PUR |
 |
BMF 08M-NS-C-2-KPU-02 | BMF000M | Brass | Ø 8 x 30.5 mm | NPN Normally open (NO) | Cable, 2.00 m, PUR | |
|
BMF 08M-NS-C-2-KPU-03 | BMF000N | Brass | Ø 8 x 30.5 mm | NPN Normally open (NO) | Cable, 3.00 m, PUR | |
|
BMF 08M-PS-C-2-KPU-02 | BMF000P | Brass | Ø 8 x 30.5 mm | PNP Normally open (NO) | Cable, 2.00 m, PUR | |
|
BMF 08M-PS-C-2-KPU-03 | BMF000R | Brass | Ø 8 x 30.5 mm | PNP Normally open (NO) | Cable, 3.00 m, PUR | |
|
BMF 08M-PS-C-2-KPU-05 | BMF000T | Brass | Ø 8 x 30.5 mm | PNP Normally open (NO) | Cable, 5.00 m, PUR | |
 |
BMF 10E-PS-D-2-SA1-S49 | BMF001Z | 1.4571 | Ø 10 x 32 mm | PNP Normally open (NO) | ||
 |
BMF 12M-NO-C-2-S4 | BMF00EC | Brass | Ø 12 x 50 mm | NPN Normally closed (NC) | M12x1-Male, 4-pole, A-coded | |
|
BMF 12M-NS-C-2-S4 | BMF00EA | Brass | Ø 12 x 50 mm | NPN Normally open (NO) | M12x1-Male, 4-pole, A-coded | |
 |
BMF 12M-NS-D-2-S4 | BMF0021 | Brass | Ø 12 x 50 mm | NPN Normally open (NO) | M12x1-Male, 4-pole, A-coded | |
|
BMF 12M-PO-C-2-S4 | BMF00E9 | Brass | Ø 12 x 50 mm | PNP Normally closed (NC) | M12x1-Male, 4-pole, A-coded | |
|
BMF 12M-PS-C-2-S4 | BMF00C7 | Brass | Ø 12 x 50 mm | PNP Normally open (NO) | M12x1-Male, 4-pole, A-coded | |
|
BMF 12M-PS-D-2-S4 | BMF0022 | Brass | Ø 12 x 50 mm | PNP Normally open (NO) | M12x1-Male, 4-pole, A-coded |
