Performance

Max. Kv-value

6,6 x 10-2

Max. heating temperature

200°C



Mechanical /Electrical specifications

Material (wetted parts)

Stainless steel 316L or comparable

Pressure rating

100 bar(a)

Max. ΔP

5...40 bar (depends on Kv-value; contact your distributor for details)

Process connections

Gas and liquid inlet: compression type or face seal couplings;
Vapour outlet: 1/4" tube (other options on request);
Purge connection: 1/8" OD or 1/8" face seal

Seals

Metal-to-metal

Plunger

Kalrez®; other on request

Protection class

IP40

Power supply

Mixing valve: +/-15...24 Vdc;
Heater: 110-120 Vac or 220-240 Vac

Power consumption

Mixing valve: 4 W (max.);
Heater: 1375 W (nominal)

Heater capacity

1000 W

Connector 1 (temperature & safety)

Amphenol 6-pin male

Connector 2 (heater)

Amphenol 5-pin male
